Development and Application of an Autonomous Inflow Control Device in Horizontal Wells
-
摘要: 针对边底水油藏水平井由于跟端趾端效应和水平段地层非均质性造成含水率快速升高的情况,在分析油水物性和调流控水筛管应用工艺的基础上,利用层流与紊流的流动特性,研制了一种能够根据产出流体的情况自动调节附加阻力的"主动式"自适应调流控水装置。流体动力学流场模拟及室内性能试验结果表明,油水流经自适应调流控水装置时,油相的摩阻低、水相的摩阻高,最大水油压降比可达10.0以上,具有自动调节油水附加阻力的功能。自适应调流控水装置在塔河油田底水油藏水平井A井进行了现场试验,与未应用调流控水装置的邻井相比,低含水采油期延长3个月以上。研究与试验表明,自适应调流控水装置可以根据产出流体的情况,自动对产出水进行节流,解决了边底水油藏水平井底水锥进的问题。Abstract: For horizontal wells in oil reservoirs with edge water or bottom water, the heel and toe effect and the heterogeneity of horizontal section can lead to a rapid increase of water content. Through the analysis of oil/water properties and flow adjustment and water control screen pipe techniques, and a consideration of the features of laminar flow and turbulent flow, an "active" autonomous inflow control device (AICD) was developed which could automatically adjust additional resistance depending on fluids produced. The hydrodynamics flow field simulation and lab test showed low friction of oil and high friction of water when oil and water flow through the AICD, with the maximum water-oil pressure drop ratio up to 20 or more. Thus, the additional resistance of oil and water was adjusted automatically. A field test of AICD was conducted in Well A, while a horizontal well in oil reservoir with bottom water, Tahe Oilfield. Compared with adjacent wells with no AICD applied, the oil production period of Well A with low water content was postponed for 3 months or longer. The study and test revealed that the AICD could throttle the water produced automatically depending on the fluids produced, so as to avoid bottom water coning in oil reservoirs with edge water or bottom water.
-
-
[1] 王金忠,肖国华,陈雷,等.水平井管内分段调流控水技术研究与应用[J].石油机械,2011,39(1):60-61. WANG Jinzhong,XIAO Guohua,CHEN Lei,et al.Research and application of the staged flow-regulating and water-control technology with screen or tubing in horizontal holes[J].China Petroleum Machinery,2011,39(1):60-61. [2] 李良川,肖国华,王金忠,等.冀东油田水平井分段控水配套技术[J].断块油气田,2010,17(6):655-658. LI Liangchuan,XIAO Guohua,WANG Jinzhong,et al.Sectionalized water control matching technology of horizontal well in Jidong Oilfield[J].Fault-Block Oil Gas Field,2010,17(6):655-658. [3] 王超,张军杰,刘广燕.水平井分段控水完井试油技术[J].石油天然气学报,2010,32(6):446-449. WANG Chao,ZHANG Junjie,LIU Guangyan.Research on sectionalized water control well completion and oil testing technology of horizontal well[J].Journal of Oil and Gas Technology,2010,32(6):446-449. [4] 强晓光,姜增所,宋颖智.调流控水筛管在冀东油田水平井的应用研究[J].石油矿场机械,2011,40(4):77-79. QIANG Xiaoguang,JIANG Zengsuo,SONG Yingzhi.Research and application of water control screen pipe in Jidong Oilfield horizontal well[J].Oil Field Equipment,2011,40(4):77-79. [5] OUYANG Liangbiao.Pratical consideration of an inflow-control device application for reducing water production[R].SPE 124154,2009.
[6] AL ARFI S A,MOHAMED O Y,KESHKA A A,et al.Inflow control device an innovative completion solution from "extended wellbore to extended well life cycle"[R].SPE 119599,2008.
[7] AUGUSTINE J R.An investigation of the economic benefit of inflow control devices on horizontal well completions using a reservoir-wellbore coupled model[R].SPE 78293,2002.
[8] EDMUNDO D,ROBERO A,PAZ F,et al.First applications of inflow control devices(ICD) in open hole horizontal wells in Block 15,Ecuador[R].SPE 123008,2009.
[9] 中国石油集团西部钻探工程有限公司.筛管控水装置:20101026-0028[P].2011-08-31. CNPC Xibu Drilling Engineering Company Limited.Screen water control device:201010260028[P].2011-08-31. [10] 淄博东森石油技术发展有限公司.调压控水防砂管:20112007-1460[P].2011-08-31. Zibo Dongsen Petroleum Technology Development Company Limited.Adjusted water control screen pipe:201120071460[P].2011-08-31. [11] 周桂军,田继民,杨永超.一种可调式控水器:201020105465[P].2010-10-06. ZHOU Guijun,TIAN Jimin,YANG Yongchao.A adjustable water control device:201020105465[P].2010-10-06. [12] 徐鑫.水平井控流筛管完井技术研究及应用[J].石油钻探技术,2014,42(3):71-75. XU Xin.Development and application of flow control screen completion for horizontal wells[J].Petroleum Drilling Techniques,2014,42(3):71-75. [13] 王庆,刘慧卿,张红玲,等.油藏耦合水平井调流控水筛管优选模型[J].石油学报,2011,32(2):346-349. WANG Qing,LIU Huiqing,ZHANG Hongling,et al.An optimization model of completion strings with inner-located nozzle in horizontal wells coupled with reservoirs[J].Acta Petrolei Sinica,2011,32(2):346-349. [14] OSTROWSKI L P,GALIMZYANOV A R,UELKER B.Advances in modeling of passive inflow control devices help optimizing horizontal well completions[R].SPE 135998,2010.
[15] NEYLON K J,REISO E,HOLMES J A,et al.Modeling well inflow control with flow in both annulus and tubing[R].SPE 118909,2009.
[16] RAFFN A G,ZEYBEK M,MOEN T,et al.Case histories of improved horizontal well cleanup and sweep efficiency with nozzle based inflow control devices in sandstone and carbonate reservoirs[R].OTC 19172,2008.
[17] HENRIKSEN K H,GULE E I,AUGUSTINE J R.Case study:the application of inflow control devices in the troll field[R].SPE 100308,2006.
[18] OUYANG Liangbiao,ARBABI S,AZIZ K.General wellbore flow model for horizontal,vertical,and slanted well completions[R].SPE 36608,1998.
-
