Emergency Techniques for a Simple Blowout Preventer in the Case of a Deepwater Blowout
-
摘要: 为有效解决深水井喷失控问题,研究了简易防喷器应急技术.采用预先危险性分析方法评估了简易防喷器作业风险,建立了隔水管-简易防喷器-导管耦合系统力学模型,研究了简易防喷器组合类型和配置方案的确定方法.以南海深水某油井为例,研究了顶张力、钻井船偏移、海流和关井压力对简易防喷器作业性能的影响,并基于极差分析和方差分析方法确定了影响简易防喷器作业性能的主要因素.研究表明,简易防喷器闸板数量对导管应力影响较小,为提高简易防喷器系统的可靠性,可选取五闸板简易防喷器;影响导管最大等效应力的因素依次为钻井船偏移、关井压力、海流流速和顶张力.根据简易防喷器应急技术研究结果进行应急预案制订和现场作业设计,可保障深水井喷应急作业的安全开展.Abstract: To effectively resolve the problem of out-of-control blowouts in deepwater wells,the research was conducted on the emergency technique of a simple blowout preventer for deepwater blowouts.The preliminary hazard analysis (PHA) was used for evaluating operation risks of the simple BOP and a mechanical analysis model was built for riser pipe-simple BOP-conductor coupling system to research a method for determining combination form and configuration scheme of the simple BOP.Some oil wells in the South China Sea were taken as examples to research the effects of top tension,drilling ship deviation,ocean current and shut-in pressure on operation performance of the simple BOP.Then,the goal was to determine important factors affecting operation performance of the simple BOP based on range and variance analysis.Research results showed that the ram quantity of the simple BOP had a small effect in conductor stress and five-ram simple BOP could be selected to improve system reliability of the simple BOP.The factors affecting maximum equivalent stress of the conductor were drilling vessel deviation,shut-in pressure,ocean current velocity and top tension.The research on emergency technique of simple blowout preventer could be carried out for emergency plan preparation and site operation design to ensure the safe implementation of emergency operations for deepwater blowouts.
-
Keywords:
- deepwater /
- blowout /
- simple blowout preventer /
- mechanical model /
- configuration scheme /
- sensitivity analysis
-
-
[1] 金业权,胡满,吴谦,等.Macondo深水井漏油事故防喷器系统失效原因分析[J].石油钻探技术,2014,42(4):53-58. Jin Yequan,Hu Man,Wu Qian,et al.Analysis of deepwater BOP failure in the Macondo Well accident[J].Petroleum Drilling Techniques,2014,42(4):53-58. [2] 魏超南,陈国明.深水地平线钻井平台井喷事故剖析与对策探讨[J].钻采工艺,2012,35(5):18-21. Wei Chaonan,Chen Guoming.Analysis and pecaution of the blowout on Deepwater Horizon rig[J].Drilling Production Technology,2012,35(5):18-21. [3] 高永海,孙宝江,曹式敬,等.应用事故树法对深水井控进行风险评估[J].石油钻采工艺,2008,30(2):23-27. Gao Yonghai,Sun Baojiang,Cao Shijing,et al.Risk assessment on well control in deepwater drilling based on fault tree analysis[J].Oil Drilling Production Technology,2008,30(2):23-27. [4] 付建民,郑晓云.井控作业危险性HAZOP分析技术[J].安全与环境工程,2005,12(4):89-91. Fu Jianmin,Zheng Xiaoyun.HAZOP technology on risk in well control operations[J].Safety and Environmental Engineering,2005,12(4):89-91. [5] 畅元江.深水钻井隔水管设计方法及其应用研究[D].青岛:中国石油大学(华东)机电工程学院,2008. Chang Yuanjiang.Designapproach and its application for deepwater drilling risers[D].Qingdao:China University of Petroleum(Huadong),College of Mechanical and Electromechanical Engineering,2008. [6] National Commission on the BP Deepwater Horizon Oil Spill and Offshore Drilling.Deep water:the gulf oil disaster and the future of offshore drilling[R].2011.
[7] 孟会行,陈国明,朱渊,等.深水井喷应急技术分类及研究方向探讨[J].石油钻探技术,2012,40(6):27-32. Meng Huixing,Chen Guoming,Zhu Yuan,et al.Classification and discussion on the direction of emergency technology for deepwater blowout[J].Petroleum Drilling Techniques,2012,40(6):27-32. [8] Hickman S H,Hsieh P A,Mooney W D,et al.Scientific basis for safely shutting in the Macondo Well after the April 20,2010 deepwater horizon blowout[J].PNAS,2012,109(50):20268-20273.
[9] Rassenfoss S.Well capping becomes an industry of its own[J].Journal of Petroleum Technology,2013,65(7):41-47.
[10] Chen Jack,Li Xunke,Xie Wenhui,et al.Capping stack:an industry in the making[J].Engineering Sciences,2013,11(4):17-23.
[11] Massey M.Marine well containment company progress[R].OTC 23596,2012.
[12] Hurzeler K.The development and maintenance of an "evergreen" spill response capability in the Gulf of Mexico[R].OTC 23691,2012.
[13] American Petroleum Institute.API RP 17W recommended practice for subsea capping stacks[S].
[14] Smith L M.A review of offshore blowouts and spills to determine desirable capabilities of a subsea capping stack[D].Baton Rouge:Louisiana State University,2012.
[15] Vinnem J E.Offshore risk assessment[M].London:Springer-Verlag,2007:164.
[16] 孙友义.深水钻井隔水管强度评价方法及应用研究[D].青岛:中国石油大学(华东)机电工程学院,2009. Sun Youyi.Strength assessment for deepwater drilling riser and engineering application[D].Qingdao:China University of Petroleum(Huadong),College of Mechanical and Electromechanical Engineering,2009. [17] 鞠少栋,畅元江,陈国明,等.深水钻井隔水管连接作业窗口分析[J].石油勘探与开发,2012,39(1):105-110. Ju Shaodong,Chang Yuanjiang,Chen Guoming,et al.Envelopes for connected operation of the deepwater drilling riser[J].Petroleum Exploration and Development,2012,39(1):105-110. [18] 苏堪华.深水钻井井口力学分析及管承载能力研究[D].青岛:中国石油大学(华东)石油工程学院,2009. Su Kanhua.Analysis onmechanical stability of subsea wellhead and bearing capacity of conductor for deepwater drilling[D].Qingdao:China University of Petroleum(Huadong),School of Petroleum Engineering,2009. [19] American Petroleum Institute.API RP53-1997 recommended practices for blowout prevention equipment systems for drilling wells[S].
[20] 鞠少栋,陈国明,盛磊祥,等.基于CFD的深水隔水管螺旋列板几何参数优选[J].中国石油大学学报:自然科学版,2010,34(2):112-113. Ju Shaodong,Chen Guoming,Sheng Leixiang,et al.CFD-based optimization for geometric parameters of deepwater riser helical strakes[J].Journal of China University of Petroleum:Edition of Natural Science,2010,34(2):112-113. -
