Managed Pressure Drilling Technique in the Well Y26ST of YD Oilfield
-
摘要: YD油田Y26井在钻进Kazhdumi组地层时有大量沥青和硫化氢侵入,造成井涌与井漏并存的井下复杂情况,采取多种方法处理未见效果,被迫临时弃井.Y26ST井为Y26井的侧钻井眼,基于原井眼沥青侵处理过程中获得的经验与教训,针对侧钻要求,开展了控制压力钻井技术适应性评价和控制压力钻井风险分析,并形成了Y26ST井控制压力钻井技术方案.侧钻过程中,根据实际情况,依次采用了井底恒压和加压泥浆帽2种控制压力钻井方法,有效控制了井筒内的压力分布,降低了沥青侵、油气侵和井漏等井下复杂情况对钻井工程的危害.Y26ST井顺利钻穿Kazhdumi组湿沥青层段,成功下入尾管并固井.控制压力钻井技术在Y26ST井的成功应用,为活跃沥青层长裸眼安全钻进提供了新的技术手段.Abstract: Large volume of bitumen and hydrogen sulfide flew into Well Y26 in the YD Oilfield while drilling into the Kazhdumi Formation, which resulted in the complexity of coexisting well kicks and lost circulation. Some methods were used to kill the well, but they were all unsatisfactory. Finally, the well was temporarily abandoned. Well Y26ST is a sidetracked hole of Well Y26. On the basis of experience gained from handling the bitumen in the original borehole, assessments for applicability and risks related to managed pressure drilling were conducted, so as to generate a drilling program for Well Y26ST. To cope with the kick of formation fluids during drilling, the methods both constant bottom hole pressure and pressured mud cap were used during sidetracking operation, the borehole pressures was controlled effectively, the invasion of wet bitumen, heavy oil and gas was minimized, lost circulation and other troubles in drilling were also avoided. Well Y26ST was penetrated the wet bitumen interval and cemented with liner successfully in Kazhdumi Formation,which shows that success of managed pressure drilling in Well Y26ST can provide a reference for drilling a long open-hole interval within active bitumen formation.
-
Keywords:
- managed pressure drilling /
- mud cap /
- bottom hole pressure /
- Well Y26ST /
- YD Oilfield
-
-
[1] 金军斌,何青水,唐文泉,等.Y油田超厚沥青层安全钻进分强度控制技术[J].石油钻探技术,2015,43(1):63-68. Jin Junbin,He Qingshui,Tang Wenquan,et al.Contamination control technique for safe drilling in ultra-thick asphalt layers in Y Oilfield [J].Petroleum Drilling Techniques,2015,43(1):63-68. [2] 何青水,宋明全,肖超,等.非均质超厚活跃沥青层安全钻井技术探讨[J].石油钻探技术,2013,41(1):20-24. He Qingshui,Song Mingquan,Xiao Chao,et al.Discussion on safe drilling technology for heterogeneous,ultra-thick and active bitumen zone[J].Petroleum Drilling Techniques,2013,41(1):20-24. [3] 张涛,李军,柳贡慧,等.控压钻井自动节流管汇压力调节特性研究[J].石油钻探技术,2014,42(2):18-22. Zhang Tao,Li Jun,Liu Gonghui,et al.Pressure regulation characteristics of automatic choke manifold in managed pressure drilling[J].Petroleum Drilling Techniques,2014,42(2):18-22. [4] 燕修良,朱焕刚,李宗清,等.控制压力钻井气体溢流处理方法分析与改进[J].石油钻采工艺,2014,36(5):62-64. Yan Xiuliang,Zhu Huangang,Li Zongqing,et al.Analysis and improvement of gas overflow treatment in managed pressure drilling [J].Oil Drilling Production Technology,2014,36(5):62-64. [5] 李军伟,曹式敬,宋林松,等.JZ25-1S油田水平井控制压力钻井技术[J].石油钻探技术,2013,41(2):119-122. Li Junwei,Cao Shijing,Song Linsong,et al.Managed pressure drilling technique for horizontal wells in JZ25-1S Oilfield[J].Petroleum Drilling Techniques,2013,41(2):119-122. [6] 宋巍,李永杰,靳鹏菠,等.裂缝性储层控压钻井技术及应用[J].断块油气田,2013,20(3):362-365. Song Wei,Li Yongjie,Jin Pengbo,et al.MPD technology on fractured reservoir and its application[J].Fault-Block Oil Gas Field,2013,20(3):362-365. [7] 向雪琳,朱丽华,单素华,等.国外控制压力钻井工艺技术[J].钻采工艺,2009,32(1):27-30. Xiang Xuelin,Zhu Lihua,Shan Suhua,et al.Foreign managed pressure drilling technology[J].Drilling and Production Technology,2009,32(1):27-30. [8] Hannegan D,Todd R J,Pritchard D M,et al.MPD—uniquely applicable to methane hydrate drilling[R].SPE/ IADC 91560,2004.
[9] Medley G H,Reynolds P B B.Distinct variations of managed pressure drilling exhibit application potential[J].World Oil,2006,227 (3): 41-44.
[10] Silvang S A,Leuchtenberg C,Gil I C,et al.Managed-pressure drilling resolves pressure depletion-related problems in the development of the high-pressure high-temperature Kristin Field[R].SPE/IADC 113672,2008.
[11] Reitsma D,van Riet E.Feasibility study of utilizing an automated annular pressure control system for managed pressure drilling in Mature Offshore Oilfields[R].SPE 96646,2005.
[12] Hannegan D M.Case studies-offshore manag edpressure drilling[R].SPE 101855,2006.
[13] Rehman S A. 3D managed-pressure drilling around a sault dome using coiled tubing: a case study—challenges and solutions[R].SPE 102608,2006.
[14] Runtuwene M,Suprihono S,Rizka D,et al.Pressurized mud cap drilling drastically reduces non-productive time in Soka Field,South Sumatera[R].SPE/IADC 125311,2009.
[15] Niznik M R,Elks W C,Zeilinger S C.Pressurized mud cap drilling in Qatar’s North Field[R].SPE 122204,2009.
-
