Coring Challenges and Solutions in the YD Oilfield
-
摘要: YD油田早期探井的岩心资料不全,且岩心收获率偏低.为补全岩心资料,提高该油田的岩心收获率,针对该油田取心井段地层溶洞发育、易破碎,地层岩性非均质强,软硬地层交错且高含H2S等特点,在分析该油田钻井取心技术难点的基础上,结合该油田的钻井取心实践,从取心工具的选择、井眼准备、下钻、取心参数的优化、割心及起钻等方面,提出了提高YD油田岩心收获率的技术对策,并在YD油田APP3井和F09井钻井取心时进行了现场试验,2口井的岩心收获率得到大幅提高.这表明,该取心技术对策可以解决YD油田钻井取心存在的技术难点.Abstract: In the YD Oilfield, early wildcat wells provided only limited core data and there was low core recovery. In order to acquire enough core data and to improve the core recovery in this oilfield, coring challenges were first analyzed, since the coring intervals were prone to break due to existence of dissolved caves and the fact they contained alternating hard and soft formations with high heterogeneity and high H2S. Then, considering these challenges and the practice of coring in this oilfield, a specific coring solution was proposed for the YD Oilfield, that included consideration of aspects of coring tools selection, wellbore preparation, runing in hole, coring parameters optimization, core cutting and pulling out of hole. In addition, this article also demonstrates the coring drilling experiences in Well APP3 and F09. The solution was applied in Wells APP3 and F09,and their core recovery rate in these wells significantly improved. The results indicate that the proposed solution could effectively address the challenges of coring in this oilfield.
-
Keywords:
- coring /
- core recovery rate /
- coring tools /
- YD Oilfield
-
-
[1] 鲍洪志,杨顺辉,侯立中,等.伊朗Y油田F地层防卡技术[J].石油钻探技术,2013,41(3):67-72. Bao Hongzhi,Yang Shunhui,Hou Lizhong,et al.Pipe sticking prevention measures in F Formation of Iranian Y Oilfield[J].Petroleum Drilling Techniques,2013,41(3):67-72. [2] 周成贵.在取心钻进中产生磨心的原因及其预防[J].钻采工艺,1990,13(4):15-17. Zhou Chenggui.The reasons and preventions of jamming during coring operation[J].Drilling Production Technology,1990,13(4):15-17. [3] Briner A P,Azzouni A,Chitnis R,et al.Sweet success in sour coring[R].SPE 128007,2010.
[4] Khan A M,Onezime J,Mosalem D,et al.Successful coring in 8.5-in.hole section using anti-jamming technology in Southern Iraq[R].SPE 172099,2014.
[5] Salman Z,Asif K,Asif K,et al.Applications of state of the art anti-jam coring system:a case study[R].SPE 156208,2011.
[6] 孔志刚,于希.辽河油田古潜山储层钻井取心技术[J].石油钻探技术,2014,42(3):50-54. Kong Zhigang,Yu Xi.Coring techniques for buried hill reservoirs in Liaohe Oilfield[J].Petroleum Drilling Techniques,2014,42(3):50-54. [7] Sino L A,Warren T M,Armagost W K,et al.Development of an antiwhirl core bit[R].SPE 24587,1995.
[8] 许俊良,宋维华,任红.老油区疏松地层取心关键技术研究及现场应用[J].石油钻探技术,2012,40(5):26-29. Xu Junliang,Song Weihua,Ren Hong.Research and field application of key coring technology for unconsolidated formation in matured oilfield[J].Petroleum Drilling Techniques,2012,40(5):26-29. [9] 任立伟,夏柏如,唐文泉,等.伊朗Y油田深部复杂地层钻井液技术[J].石油钻探技术,2013,41(4):92-96. Ren Liwei,Xia Bairu,Tang Wenquan,et al.Drilling fluid technology for deep troublesome formation of Y Oilfield in Iran[J].Petroleum Drilling Techniques,2013,41(4):92-96. [10] 王兴武,李让,王万红.我国西部地区超深井钻井取心技术[J].天然气工业,2010,30(11):63-66. Wang Xingwu,Li Rang,Wang Wanhong.Coring technology in ultra-deep wells in West China[J].Natural Gas Industry,2010,30(11):63-66. -
