南川页岩气田超长水平段水平井钻井关键技术

姜政华 孙钢 陈士奎 李伯尧 董红烨

姜政华,孙钢,陈士奎,等. 南川页岩气田超长水平段水平井钻井关键技术[J]. 石油钻探技术,2022, 50(5):20-26 doi: 10.11911/syztjs.2022045
引用本文: 姜政华,孙钢,陈士奎,等. 南川页岩气田超长水平段水平井钻井关键技术[J]. 石油钻探技术,2022, 50(5):20-26 doi: 10.11911/syztjs.2022045
JIANG Zhenghua, SUN Gang, CHEN Shikui, et al. Key drilling technologies for horizontal wells with ultra-long horizontal sections in Nanchuan Shale Gas Field [J]. Petroleum Drilling Techniques,2022, 50(5):20-26 doi: 10.11911/syztjs.2022045
Citation: JIANG Zhenghua, SUN Gang, CHEN Shikui, et al. Key drilling technologies for horizontal wells with ultra-long horizontal sections in Nanchuan Shale Gas Field [J]. Petroleum Drilling Techniques,2022, 50(5):20-26 doi: 10.11911/syztjs.2022045

南川页岩气田超长水平段水平井钻井关键技术

doi: 10.11911/syztjs.2022045
基金项目: 中国石化科技攻关项目“常压页岩气钻完井及配套工艺技术研究”(编号:P21087)资助
详细信息
    作者简介:

    姜政华 (1974—),男,安徽黄山人,1994年毕业于长春地质学校探矿工程专业,工程师,主要从事页岩气钻井技术研究及相关管理工作。E-mail:295844502@qq.com。

  • 中图分类号: TE243+.1

Key Drilling Technologies for Horizontal Wells with Ultra-Long Horizontal Sections in Nanchuan Shale Gas Field

  • 摘要:

    南川常压页岩气田采用超长水平段水平井开发可提高其开发效益,但存在水平段极限延伸能力预测难、井眼轨迹控制难、井眼清洁效果差、钻柱摩阻扭矩大、套管下入难和固井易漏易气窜等技术挑战。为此,进行了管柱力学和流体力学分析,明确了超长水平段钻进和下套管时钻柱的受力状态,分析了超长水平段的水力延伸能力及关键影响因素。基于分析结果和南川页岩气田钻井实践,形成了井眼轨道优化设计、低成本高效导向钻井、井眼高效清洁、套管安全下入、超长水平段泡沫水泥浆固井等关键技术。上述技术在2口水平段长度超3 500 m的水平井进行了现场应用,全部使用国产的钻头、螺杆钻具及常规LWD,2口井平均钻井完井周期较设计缩短25.4%,实钻整体靶框控制在5 m以内,优质页岩钻遇率平均在90%以上,水平段复合钻进比例平均达90.45%,最大狗腿度0.15°/30m,高效成井的同时,实现了提速降本。南川页岩气田超长水平段水平井钻井关键技术,可为国内水平段长超3 500 m水平井的钻井提速提供借鉴。



  • 图 1  螺杆弯角对螺杆钻具造斜率的影响

    Figure 1.  Influence of screw bend on build-up rate of PDM

    图 2  常规水泥浆失重气窜现象与泡沫水泥浆防气窜作用示意

    Figure 2.  Gas channeling in conventional cement slurry under weightlessness and the role of foamed cement slurry in preventing gas channeling

    表  1  固井下套管摩阻与水平段长度及摩阻系数的关系

    Table  1.   Relationship between friction of casing running and horizontal section length as well as friction coefficient

    水平段
    长度/m
    不同摩阻系数对应的套管下入摩阻/kN
    0. 150. 200. 250. 30
    1 000 63.96 98.40132.84167.28
    1 500 79.95123.00166.05209.10
    2 000 95.94147.60199.26250.92
    2 500113.88175.20236.52297.84
    3 000131.82202.80273.78344.76
    3 500151.16232.00312.84393.68
    4 000170.50261.20351.90442.60
    下载: 导出CSV

    表  2  不同井身剖面对应的摩阻、扭矩对比

    Table  2.   Friction and torque values of different well profiles

    井身剖面最大狗腿度/
    ((°)·(30m)−1
    地面扭矩1)/
    (kN·m)
    摩阻/kN钻具疲劳
    系数
    钻具屈曲时的钻压/kN
    起钻下钻复合钻进滑动钻进
    类双二维523.437.513.90.27320130
    五段制525.337.615.60.28280 50
    注:1)用100 kN钻压模拟地面扭矩。
    下载: 导出CSV

    表  3  水力振荡器应用情况

    Table  3.   Applications of hydraulic oscillator

    井号井段/m进尺/m井段工具入井时间/h减阻效果,%
    SYX-2HF3 268~4 3881 606造斜段,水平段175.033.2
    4 388~4 874水平段120.0
    SYX-5HF3 687~4 385 698水平段203.534.6
    下载: 导出CSV
  • [1] 何希鹏,高玉巧,唐显春,等. 渝东南地区常压页岩气富集主控因素分析[J]. 天然气地球科学,2017,28(4):654–664.

    HE Xipeng, GAO Yuqiao, TANG Xianchun, et al. Analysis of major factors controlling the accumulation in normal pressure shale gas in the Southeast of Chongqing[J]. Natural Gas Geoscience, 2017, 28(4): 654–664.
    [2] 孙永兴,贾利春. 国内3 000 m长水平段水平井钻井实例与认识[J]. 石油钻采工艺,2020,42(4):393–401.

    SUN Yongxing, JIA Lichun. Cases and understandings on the drilling of horizontal well with horizontal section of 3 000 m long in China[J]. Oil Drilling & Production Technology, 2020, 42(4): 393–401.
    [3] 彭兴,周玉仓,龙志平,等. 南川地区页岩气水平井优快钻井技术进展及发展建议[J]. 石油钻探技术,2020,48(5):15–20. doi: 10.11911/syztjs.2020057

    PENG Xing, ZHOU Yucang, LONG Zhiping, et al. Progress and development recommendations for optimized fast drilling technology in shale gas horizontal wells in the Nanchuan Area[J]. Petroleum Drilling Techniques, 2020, 48(5): 15–20. doi: 10.11911/syztjs.2020057
    [4] 李东杰,王炎,魏玉皓,等. 页岩气钻井技术新进展[J]. 石油科技论坛,2017,36(1):49–56.

    LI Dongjie, WANG Yan, WEI Yuhao, et al. Latest shale gas drilling technological development[J]. Petroleum Science and Technology Forum, 2017, 36(1): 49–56.
    [5] 席传明,史玉才,张楠,等. 吉木萨尔页岩油水平井JHW00421井钻完井关键技术[J]. 石油钻采工艺,2020,42(6):673–678. doi: 10.13639/j.odpt.2020.06.001

    XI Chuanming, SHI Yucai, ZHANG Nan, et al. Key technologies for the drilling and completion of shale oil horizontal Well JHW00421 in Jimusaer[J]. Oil Drilling & Production Technology, 2020, 42(6): 673–678. doi: 10.13639/j.odpt.2020.06.001
    [6] 李传武,兰凯,杜小松,等. 川南页岩气水平井钻井技术难点与对策[J]. 石油钻探技术,2020,48(3):16–21. doi: 10.11911/syztjs.2020055

    LI Chuanwu, LAN Kai, DU Xiaosong, et al. Difficulties and countermeasures in horizontal well drilling for shale gas in Southern Sichuan[J]. Petroleum Drilling Techniques, 2020, 48(3): 16–21. doi: 10.11911/syztjs.2020055
    [7] 谭玮,房舟,罗成波,等. 致密高应力水平井优快钻完井难点与对策[J]. 断块油气田,2020,27(5):653–656. doi: 10.6056/dkyqt202005021

    TAN Wei, FANG Zhou, LUO Chengbo, et al. Difficulties and solutions of optimized fast drilling and completion of horizontal well in tight and high stressed formation[J]. Fault-Block Oil & Gas Field, 2020, 27(5): 653–656. doi: 10.6056/dkyqt202005021
    [8] 谭天一. 长水平段水平井摩阻扭矩预测与顶驱扭摆减阻技术研究[D]. 北京: 中国石油大学(北京), 2018.

    TAN Tianyi. The study of the torque and drag prediction for long horizontal section wells and the top drive oscillation friction reducing technology[D]. Beijing: China University of Petroleum (Beijing), 2018.
    [9] 郭元恒,何世明,刘忠飞,等. 长水平段水平井钻井技术难点分析及对策[J]. 石油钻采工艺,2013,35(1):14–18. doi: 10.3969/j.issn.1000-7393.2013.01.006

    GUO Yuanheng, HE Shiming, LIU Zhongfei, et al. Difficulties and countermeasures for drilling long lateral-section horizontal wells[J]. Oil Drilling & Production Technology, 2013, 35(1): 14–18. doi: 10.3969/j.issn.1000-7393.2013.01.006
    [10] 陈海宇,王新东,林晶,等. 新疆吉木萨尔页岩油超长水平段水平井钻井关键技术[J]. 石油钻探技术,2021,49(4):39–45.

    CHEN Haiyu, WANG Xindong, LIN Jing, et al. Key drilling techniques for horizontal wells with ultra-long horizontal section in the shale oil reservoir in Jimusar, Xinjiang[J]. Petroleum Drilling Techniques, 2021, 49(4): 39–45.
    [11] 王建龙,齐昌利,柳鹤,等. 沧东凹陷致密油气藏水平井钻井关键技术[J]. 石油钻探技术,2019,47(5):11–16.

    WANG Jianlong, QI Changli, LIU He, et al. Key technologies for drilling horizontal wells in tight oil and gas reservoirs in the Cangdong Sag[J]. Petroleum Drilling Techniques, 2019, 47(5): 11–16.
    [12] 胥豪,邓红琳,牛洪波,等. 大牛地气田长水平段水平井优化设计与施工:以DP31H井为例[J]. 钻采工艺,2013,36(5):26–29. doi: 10.3969/J.ISSN.1006-768X.2013.05.07

    XU Hao, DENG Honglin, NIU Hongbo, et al. Optimizing design and construction of horizontal well with long horizontal section in Daniudi Gas Field[J]. Drilling & Production Technology, 2013, 36(5): 26–29. doi: 10.3969/J.ISSN.1006-768X.2013.05.07
    [13] 胡春锋,梅俊伟,李仕钊,等. 四川盆地东部南川常压页岩气开发效果地质与工程因素分析[J]. 油气藏评价与开发,2021,11(4):559–568. doi: 10.13809/j.cnki.cn32-1825/te.2021.04.012

    HU Chunfeng, MEI Junwei, LI Shizhao, et al. Analysis on geological and engineering factors of development effects on normal pressure shale gas in Nanchuan Block, eastern Suchuan Basin[J]. Reservoir Evaluation and Development, 2021, 11(4): 559–568. doi: 10.13809/j.cnki.cn32-1825/te.2021.04.012
    [14] 章敬. 非常规油藏地质工程一体化效益开发实践:以准噶尔盆地吉木萨尔凹陷芦草沟组页岩油为例[J]. 断块油气田,2021,28(2):151–155. doi: 10.6056/dkyqt202102002

    ZHANG Jing. Effective development practices of geology-engineering integration on unconventional oil reservoirs:taking Lucaogou Formation shale oil in Jimsar Sag,Junggar Basin for example[J]. Fault-Block Oil & Gas Field, 2021, 28(2): 151–155. doi: 10.6056/dkyqt202102002
    [15] 陈四平,谭判,石文睿,等. 涪陵页岩气优质储层测井综合评价方法[J]. 石油钻探技术,2020,48(4):131–138. doi: 10.11911/syztjs.2020091

    CHEN Siping, TAN Pan, SHI Wenrui, et al. A comprehensive logging evaluation method for high quality shale gas reservoirs in Fuling[J]. Petroleum Drilling Techniques, 2020, 48(4): 131–138. doi: 10.11911/syztjs.2020091
    [16] 王建龙,冯冠雄,刘学松,等. 长宁页岩气超长水平段水平井钻井完井关键技术[J]. 石油钻探技术,2020,48(5):9–14. doi: 10.11911/syztjs.2020086

    WANG Jianlong, FENG Guanxiong, LIU Xuesong, et al. Key technology for drilling and completion of shale gas horizontal wells with ultra-long horizontal sections in Changning Block[J]. Petroleum Drilling Techniques, 2020, 48(5): 9–14. doi: 10.11911/syztjs.2020086
    [17] 何立成. 胜利油田沙河街组页岩油水平井固井技术[J]. 石油钻探技术,2022,50(2):45–50. doi: 10.11911/syztjs.2022062

    HE Licheng. A cementing technology for horizontal shale oil wells in Shahejie Formation of Shengli Oilfield[J]. Petroleum Drilling Techniques, 2022, 50(2): 45–50. doi: 10.11911/syztjs.2022062
    [18] 辜涛,李明,魏周胜,等. 页岩气水平井固井技术研究进展[J]. 钻井液与完井液,2013,30(4):75–80. doi: 10.3969/j.issn.1001-5620.2013.04.023

    GU Tao, LI Ming, WEI Zhousheng, et al. Research development of horizontal shale well cementing technology[J]. Drilling Fluid & Completion Fluid, 2013, 30(4): 75–80. doi: 10.3969/j.issn.1001-5620.2013.04.023
    [19] 袁光杰,付利,王元,等. 我国非常规油气经济有效开发钻井完井技术现状与发展建议[J]. 石油钻探技术,2022,50(1):1–12. doi: 10.11911/syztjs.2022002

    YUAN Guangjie, FU Li, WANG Yuan, et al. The up-to-date drilling and completion technologies for economic and effective development of unconventional oil & gas and suggestions for further improvements[J]. Petroleum Drilling Techniques, 2022, 50(1): 1–12. doi: 10.11911/syztjs.2022002
    [20] 丁士东,陶谦,马兰荣. 中国石化固井技术进展及发展方向[J]. 石油钻探技术,2019,47(3):41–49. doi: 10.11911/syztjs.2019073

    DING Shidong, TAO Qian, MA Lanrong. Progress, outlook, and the development directions at Sinopec in cementing technology progress[J]. Petroleum Drilling Techniques, 2019, 47(3): 41–49. doi: 10.11911/syztjs.2019073
    [21] 王彦祺,贺庆,龙志平. 渝东南地区页岩气钻完井技术主要进展及发展方向[J]. 油气藏评价与开发,2021,11(3):356–364. doi: 10.13809/j.cnki.cn32-1825/te.2021.03.010

    WANG Yanqi, HE Qing, LONG Zhiping. Main progress and development direction of shale gas drilling and completion technologies in southeastern Chongqing[J]. Reservoir Evaluation and Development, 2021, 11(3): 356–364. doi: 10.13809/j.cnki.cn32-1825/te.2021.03.010
