文23储气库封堵井完整性保障技术

吴俊霞 伊伟锴 孙鹏 刘欢乐

吴俊霞,伊伟锴,孙鹏,等. 文23储气库封堵井完整性保障技术[J]. 石油钻探技术,2022, 50(5):57-62 doi: 10.11911/syztjs.2022027
引用本文: 吴俊霞,伊伟锴,孙鹏,等. 文23储气库封堵井完整性保障技术[J]. 石油钻探技术,2022, 50(5):57-62 doi: 10.11911/syztjs.2022027
WU Junxia, YI Weikai, SUN Peng, et al. Integrity assurance technologies for plugged wells in Wen 23 Gas Storage [J]. Petroleum Drilling Techniques,2022, 50(5):57-62 doi: 10.11911/syztjs.2022027
Citation: WU Junxia, YI Weikai, SUN Peng, et al. Integrity assurance technologies for plugged wells in Wen 23 Gas Storage [J]. Petroleum Drilling Techniques,2022, 50(5):57-62 doi: 10.11911/syztjs.2022027

文23储气库封堵井完整性保障技术

doi: 10.11911/syztjs.2022027
基金项目: 中国石化科技攻关项目 “文23储气库井筒完整性评价技术与标准研究”(编号:PE19015 )部分研究内容
详细信息
    作者简介:

    吴俊霞(1969—),女,河南遂平人,1994年毕业于江汉石油学院采油工程专业,高级工程师,主要从事现代完井工程方面的研究工作。E-mail: wujx.sripe@sinopec.com。

  • 中图分类号: TE822

Integrity Assurance Technologies for Plugged Wells in Wen 23 Gas Storage

  • 摘要:

    文23储气库属于枯竭砂岩气藏型储气库,建设前需要对无法再利用的老井进行封堵。为确保老井的封堵质量,保障储气库的完整性,引入挪威石油工业协会井筒完整性技术标准的井筒完整性设计理念,识别了文23储气库老井封堵前后的窜漏风险状况,设计了井屏障系统,研发了适用于高温气层的耐高温缓膨气密封封堵体系,制定了确保封堵老井井筒完整性的工艺,形成了以井屏障设计、施工和监控为基础的井筒完整性保障技术。文23储气库老井采用该技术进行封堵,现场施工成功率100%,老井封堵后的井筒完整性良好,经受住多轮次注采交变应力的长期作用。研究和现场应用结果表明,根据井筒完整性设计理念进行井筒完整性设计和施工,可以确保老井封堵后井筒长期的完整性,也可为类似储气库设计提供借鉴。



  • 图 1  文23储气库封堵井窜漏通道示意

    Figure 1.  Channeling and leakage channels in plugged well in Wen 23 Gas Storage

    图 2  文23储气库老井封堵后的井屏障

    Figure 2.  Well barrier after plugging of old well in Wen 23 Gas Storage

    图 3  稠化时间与缓凝剂加量的关系

    Figure 3.  Relationship between thickening time and retarder dosage

    图 4  稠化时间、抗压强度与胶凝固化剂加量的关系

    Figure 4.  Relationships of thickening time and compressive strength with dosage of gelling curing agent

    图 5  滞留面积与网架结构形成剂加量的关系

    Figure 5.  Relationship between retention area and dosage of grid structure forming agent

    图 6  气体突破压力与微膨胀剂加量的关系

    Figure 6.  Relationship between gas breakthrough pressure and dosage of micro-swelling agent

    表  1  封堵目的层要求

    Table  1.   Plugging requirements for the target layers

    井段状况措施
    储气层底界以
    下100 m内
    已射孔 封堵合格后,进行下步作业
    未射孔 固井质量合格,在储层底界以下100 m套管内打水泥塞;固井质量不合格,在该井段内射孔进行二次固井,再在储气层底界以下100 m井筒内打水泥塞
    储气层已射孔 先采用挤注水泥的方式封堵射孔段,封堵半径0.50~2.00 m,并在射孔段井筒中打水泥塞,水泥塞长度在储气层顶界以上不少于300 m,同时水泥塞应覆盖储气层段,其长度要达100 m以上
    未射孔 在储气层段对应的套管打水泥塞,水泥塞覆盖储气层段长度达100 m以上
    储气层以上
    100 m内
    射孔且无套管漏失 在封堵储气层所留水泥面上坐封桥塞,然后在桥塞上打水泥塞,水泥塞长度要达到100 m以上;水泥塞上注防腐加重钻井液至井口
    未射孔或套管漏失 先在封堵层段以下坐封桥塞,挤水泥封堵后,再在井筒内打水泥塞,水泥塞长度要达100 m以上;水泥塞上注防腐加重钻井液至井口
    下载: 导出CSV

    表  2  超细水泥与普通封堵剂粒度分析结果

    Table  2.   Particle size analysis results of superfine cement and ordinary plugging agent

    封堵剂粒度中值/
    μm
    粒径范围/
    μm
    不同粒径占比,%
    3~30 μm>60 μm
    超细水泥 4.4520.25~262.3771.1 5.0
    普通封堵剂20.2111.98~451.5562.016.0
    下载: 导出CSV
  • [1] NORSOK D-010—2021 Well integrity in drilling and well operations[S].
    [2] Q/SY 01037—2022 高温高压及高含硫井井筒完整性系列标准[S].

    Q/SY 01037—2022 High temperature and high pressure and high sulfur well wellbore integrity series standards[S].
    [3] 张绍槐. 井筒完整性的定义、功能、应用及进展[J]. 石油钻采工艺,2018,40(1):1–8. doi: 10.13639/j.odpt.2018.01.001

    ZHANG Shaohuai. Definition, function, application and progress of wellbore integrity[J]. Oil Drilling & Production Technology, 2018, 40(1): 1–8. doi: 10.13639/j.odpt.2018.01.001
    [4] 游子卫,游靖,高艳芳,等. 华北油田油气井永久性封井挑战及对策[J]. 石油钻采工艺,2020,42(6):731–737. doi: 10.13639/j.odpt.2020.06.011

    YOU Ziwei, YOU Jing, GAO Yanfang, et al. Challenges to the permanent well plugging of oil and gas wells in Huabei Oilfield and their countermeasures[J]. Oil Drilling & Production Technology, 2020, 42(6): 731–737. doi: 10.13639/j.odpt.2020.06.011
    [5] 苏月琦,李琦,田艳红,等. 东濮凹陷文23气田沙四段储层沉积相特征[J]. 断块油气田,2010,17(6):726–728.

    SU Yueqi, LI Qi, TIAN Yanhong, et al. Characteristics of sedimentary fades in the fourth member of Shahejie Formation in Wen 23 Gas Field, Dongpu Depression[J]. Fault-Block Oil & Gas Field, 2010, 17(6): 726–728.
    [6] 王光磊,张金成,赵明琨. 涪陵页岩气田井筒完整性实践与认识[J]. 石油机械,2018,46(5):30–34. doi: 10.16082/j.cnki.issn.1001-4578.2018.05.005

    WANG Guanglei, ZHANG Jincheng, ZHAO Mingkun. Lessons learned from wellbore integrity in Fuling shale gas field[J]. China Petroleum Machinery, 2018, 46(5): 30–34. doi: 10.16082/j.cnki.issn.1001-4578.2018.05.005
    [7] 张智,杨昆,刘和兴,等. 注水井井筒完整性设计方法[J]. 石油钻采工艺,2020,42(1):76–85. doi: 10.13639/j.odpt.2020.01.013

    ZHANG Zhi, YANG Kun, LIU Hexing, et al. A design method for the well integrity of water injector well[J]. Oil Drilling & Production Technology, 2020, 42(1): 76–85. doi: 10.13639/j.odpt.2020.01.013
    [8] 张智,周延军,付建红,等. 含硫气井的井筒完整性设计方法[J]. 天然气工业,2010,30(3):67–69.

    ZHANG Zhi, ZHOU Yanjun, FU Jianhong, et al. A method of well integrity design for sour gas wells[J]. Natural Gas Industry, 2010, 30(3): 67–69.
    [9] 何汉平. 基于多因素耦合的井筒完整性风险评价[J]. 中国安全生产科学技术,2017,13(7):168–172. doi: 10.11731/j.issn.1673-193x.2017.07.027

    HE Hanping. Risk evaluation of wellbore integrity based on multi-factor coupling[J]. Journal of Safety Science and Technology, 2017, 13(7): 168–172. doi: 10.11731/j.issn.1673-193x.2017.07.027
    [10] 王翔宇,刘文明,林志辉,等. 伊拉克南部油田ϕ244.5 mm 套管环空带压补救技术[J]. 钻井液与完井液,2021,38(3):360–364. doi: 10.3969/j.issn.1001-5620.2021.03.017

    WANG Xiangyu, LIU Wenming, LIN Zhihui, et al. Remedy of sustained casing pressure in ϕ244.5 mm casing annulus in south oilfield of Iraq[J]. Drilling Fluid & Completion Fluid, 2021, 38(3): 360–364. doi: 10.3969/j.issn.1001-5620.2021.03.017
    [11] 刘文忠. 相国寺储气库注采井完整性技术探索与实践[J]. 钻采工艺,2017,40(2):27–30. doi: 10.3969/J.ISSN.1006-768X.2017.02.09

    LIU Wenzhong. Probe on and practice of well integrity technology for injection-production wells at Xiangguosi underground gas storage[J]. Drilling & Production Technology, 2017, 40(2): 27–30. doi: 10.3969/J.ISSN.1006-768X.2017.02.09
    [12] 杨玉豪,张万栋,韩成,等. 南海高温高压气田尾管回接管柱改进及入井质量控制[J]. 断块油气田,2020,27(2):253–257. doi: 10.6056/dkyqt202002023

    YANG Yuhao, ZHANG Wandong, HAN Cheng, et al. Running quality control and structure improvement of liner tie-back string of HTHP gasfield in the South China Sea[J]. Fault-Block Oil & Gas Field, 2020, 27(2): 253–257. doi: 10.6056/dkyqt202002023
    [13] 景宏涛,彭建云,张宝,等. 迪那2井完整性评价及风险分析[J]. 石化技术,2015(1):15–16. doi: 10.3969/j.issn.1006-0235.2015.01.010

    JING Hongtao, PENG Jianyun, ZHANG Bao, et al. Integrity assessment and risk analysis on Dina NO.2 Well[J]. Petrochemical Industry Technology, 2015(1): 15–16. doi: 10.3969/j.issn.1006-0235.2015.01.010
    [14] 王秀玲,任文亮,周战云,等. 储气库固井用油井水泥增韧材料的优选与应用[J]. 钻井液与完井液,2017,34(3):89–93. doi: 10.3969/j.issn.1001-5620.2017.03.018

    WANG Xiuling, REN Wenliang, ZHOU Zhanyun, et al. Selection and application of toughening agent used in cementing gas storage well[J]. Drilling Fluid & Completion Fluid, 2017, 34(3): 89–93. doi: 10.3969/j.issn.1001-5620.2017.03.018
    [15] 张波,罗方伟,孙秉才,等. 深层油气井井筒完整性检测方法[J]. 石油钻探技术,2021,49(5):114–120. doi: 10.11911/syztjs.2021127

    ZHANG Bo, LUO Fangwei, SUN Bingcai, et al. A method for wellbore integrity detection in deep oil and gas wells[J]. Petroleum Drilling Techniques, 2021, 49(5): 114–120. doi: 10.11911/syztjs.2021127
    [16] 齐海鹰. 机械式MMR水泥承留器在储气库老井封堵中的应用[J]. 石油矿场机械,2014,43(3):84–86. doi: 10.3969/j.issn.1001-3482.2014.03.023

    QI Haiying. Application of cement retainer squeezing in job of old well plugging back in underground gas storage[J]. Oil Field Equipment, 2014, 43(3): 84–86. doi: 10.3969/j.issn.1001-3482.2014.03.023
    [17] 曹洪昌,王野,田惠,等. 苏桥储气库群老井封堵浆及封堵工艺研究与应用[J]. 钻井液与完井液,2014,31(2):55–58. doi: 10.3969/j.issn.1001-5620.2014.02.015

    CAO Hongchang, WANG Ye, TIAN Hui, et al. Plugging of old wells for building UGS in Suqiao[J]. Drilling Fluid & Completion Fluid, 2014, 31(2): 55–58. doi: 10.3969/j.issn.1001-5620.2014.02.015
    [18] 杨昌华,牛宗奎,杨斌,等. 文96枯竭气藏储气库封堵体系研究与应用[J]. 油田化学,2012,29(3):263–266. doi: 10.19346/j.cnki.1000-4092.2012.03.003

    YANG Changhua, NIU Zongkui, YANG Bin, et al. Research and application of plugging system for Wen 96 exhausted gas/oil deposits as gas storage[J]. Oilfield Chemistry, 2012, 29(3): 263–266. doi: 10.19346/j.cnki.1000-4092.2012.03.003
    [19] 李国韬,金根泰. 油气藏型储气库废弃井封堵技术浅析[J]. 油气井测试,2017,26(6):50–51. doi: 10.3969/j.issn.1004-4388.2017.06.015

    LI Guotao, JIN Gentai. Brief analysis of the plug technology to the abandoned well of oil and gas reservoir typed gas storage[J]. Well Testing, 2017, 26(6): 50–51. doi: 10.3969/j.issn.1004-4388.2017.06.015
